Linear 2 of 5
Linear 2 of 5 is a variable length, high-density, self-checking, numeric bar code that uses five black bars to define a character. Two of the bars are wide and three are narrow.
Each Linear 2 of 5 bar code consists of the following elements:
-
Leading quiet zone
-
Start character
-
Data characters
-
Optional check character
-
Stop character
-
Trailing quiet zone
Interleaved 2 of 5 and
Linear 2 of 5 bar codes are mutually incompatible. You cannot select them
together when specifying multiple bar code types.
An example of a Linear 2 of 5 bar code is shown below:
